MILLING TOOLS APPLICATION TABLE SOLID

◎ : Excellent ◯ : Good
P H M K N S
High
SIZE RANGE Carbon Alloy Prehardened Hardened Steels Hardened High
INCH / Steels Steels Steels Stainless Cast
ITEM MODEL FLUTES HELIX METRIC TYPE PAGE Steels Steels Iron Copper Graphite Aluminum Acrylic CFRP Titanium Temperature
MIN MAX ~HB225 HB225~325 HRc30~40 HRc40~45 HRc45~55 HRc55~70 Alloy
E2120 3&4Flute 60° Inch Regular Square D1/4 D3/4 1274
E2121 D7/8 D2 ◎ ◎ ○ ○
E2160 3Flute 30° Inch Short Square D1/16 D1/4 1275 ◎ ◎ ○ ○ ○

E2161 3Flute 30° Inch Long Square D1/16 D1/4 1275 ◎ ◎ ○ ○ ○
COBALT & HSS
E2237 4Flute 0° Inch Corner Rounding D1/4 D5/8 1276
E1237 ◎ ◎ ○ ○ ○
E2482 4Flute 30° Inch Regular Square D2.0 D45.0 1277
E1482 (.0787) (1.772) ◎ ◎ ○ ○ ○
E2483 2Flute 30° Inch Regular Square D2.0 D45.0 1278 ◎ ◎ ○ ○ ○
E1483 (.0787) (1.772)
