SELECTION GUIDE SOLID CARBIDE X-POWER END MILLS

◎ : Excellent ◯ : Good
P H M K N S
High
SIZE Carbon Alloy Prehardened Hardened Steels Hardened High
ITEM MODEL DESCRIPTION PAGE Steels Steels Steels Steels Stainless Cast Copper Graphite Aluminum Acrylic CFRP Titanium Temperature
Iron
Steels
MIN MAX ~HRc20 HRc20~30 HRc30~40 HRc40~45 HRc45~55 HRc55~70 Alloy
INCH
EM209 CARBIDE, 2 FLUTE LONG LENGTH BALL NOSE ◆ R1/64 R1/2 867 ○ ◎ ◎ ◎ ○ ○ ○

EM210 CARBIDE, 4 FLUTE LONG LENGTH BALL NOSE ◆ R1/16 R1/2 867 ○ ◎ ◎ ◎ ○ ○ ○

EM961 CARBIDE, 2 FLUTE MEDIUM LENGTH BALL NOSE ◆ R1/16 R1/2 868 ○ ◎ ◎ ◎ ○ ○ ○

EM962 CARBIDE, 2 FLUTE LONG REACH BALL NOSE ◆ R3/64 R3/8 869 ○ ◎ ◎ ◎ ○ ○ ○

EM960 CARBIDE, 2 FLUTE MINIATURE BALL NOSE ◆ R.012 R.031 870 ○ ◎ ◎ ◎ ○ ○

EM109 CARBIDE, 2 FLUTE 15° HELIX STUB CUT LENGTH BALL NOSE ◆ R1/64 R1/4 871 ○ ◎ ◎
for OVER HRc55

EM963 CARBIDE, 2 FLUTE BALL NOSE with TAPER NECK ◆ R1/32 R1/4 872 ○ ◎ ◎ ◎ ○ ○ ○

EM979 CARBIDE, 2 FLUTE BALL NOSE with PENCIL NECK ◆ R3/32 R1/4 873 ○ ◎ ◎ ◎ ○ ○ ○

EM084 CARBIDE, 2 FLUTE LONG LENGTH BALL NOSE ◆ R1/16 R5/16 875 ○ ◎ ◎ ◎ ○ ○ ○
(MMC-ECONOMY TYPE)

EM093 CARBIDE, 4 FLUTE LONG LENGTH BALL NOSE ◆ R1/16 R5/16 876 ○ ◎ ◎ ◎ ○ ○ ○
(MMC-ECONOMY TYPE)
CARBIDE, 2 FLUTE LONG LENGTH BALL NOSE
EM096 (MMC-SPHERE TYPE) ◆ R1/16 R5/16 877 ○ ◎ ◎ ◎ ○ ○ ○

EM097 CARBIDE, 4 FLUTE LONG LENGTH BALL NOSE ◆ R1/16 R5/16 878 ○ ◎ ◎ ◎ ○ ○ ○
(MMC-SPHERE TYPE)
EM666 CARBIDE, MULTI FLUTE 20° HELIX STUB LENGTH ◆ D1/4 D1 879 ○ ◎ ◎ ◎ ○ ○ ○
FINE PITCH ROUGHING

EM156 CARBIDE, MULTI FLUTE 20° HELIX LONG LENGTH ◆ D1/4 D1 879 ○ ◎ ◎ ◎ ○ ○ ○
FINE PITCH ROUGHING
EM662 CARBIDE, MULTI FLUTE 20° HELIX LONG LENGTH ◆ R1/8 R1/2 880 ○ ◎ ◎ ◎ ○ ○
FINE PITCH ROUGHING BALL NOSE

EM966 CARBIDE, 2 FLUTE for RIB PROCESSING ◆ D1/32 D1/8 881 ○ ◎ ◎ ◎ ○ ○

EM967 CARBIDE, 2 FLUTE BALL NOSE for RIB PROCESSING ◆ R1/64 R1/16 882 ○ ◎ ◎ ◎ ○ ○
◆ U.S.A Stock
