SELECTION GUIDE SOLID CARBIDE X-POWER END MILLS

◎ : Excellent ◯ : Good
P H M K N S
High
SIZE Carbon Alloy Prehardened Hardened Steels Hardened High
ITEM MODEL DESCRIPTION PAGE Steels Steels Steels Steels Stainless Cast Copper Graphite Aluminum Acrylic CFRP Titanium Temperature
Iron
Steels
MIN MAX ~HRc20 HRc20~30 HRc30~40 HRc40~45 HRc45~55 HRc55~70 Alloy
METRIC
EM810 CARBIDE, 2 FLUTE SHORT LENGTH ◇ D1.0 D25.0 883 ○ ◎ ◎ ◎ ○ ○ ○

EM816 CARBIDE, 2 FLUTE LONG LENGTH ◇ D2.0 D25.0 884 ○ ◎ ◎ ◎ ○ ○ ○

EM811 CARBIDE, 4 FLUTE SHORT LENGTH ◇ D2.0 D25.0 885 ○ ◎ ◎ ◎ ○ ○ ○

EM817 CARBIDE, 4 FLUTE LONG LENGTH ◇ D2.0 D25.0 886 ○ ◎ ◎ ◎ ○ ○

EM895 CARBIDE, 3 FLUTE 38° HELIX SHORT LENGTH ◇ D1.0 D20.0 887 ○ ◎ ◎ ◎ ○ ○ ○

EM810 CARBIDE, 2 FLUTE MINIATURE ◇ D0.4 D1.5 888 ○ ◎ ◎ ◎ ○ ○

EM818 CARBIDE, 2 FLUTE LONG LENGTH CORNER RADIUS ◇ D3.0 D20.0 889 ○ ◎ ◎ ◎ ○

EM819 CARBIDE, 4 FLUTE LONG LENGTH CORNER RADIUS ◇ D3.0 D20.0 889 ○ ◎ ◎ ◎ ○ ○ ○

EM905 CARBIDE, 4 FLUTE 45° HELIX SHORT LENGTH CORNER RADIUS ◇ D10.0 D22.0 890 ○ ◎ ◎ ◎ ○ ○ ○

EM839 CARBIDE, 4 FLUTE STUB CUT LENGTH CORNER RADIUS ◇ D2.0 D16.0 891 ○ ◎ ◎ ◎ ○ ○

EM812 CARBIDE, 6&8 FLUTE 45° HELIX LONG LENGTH ◇ D6.0 D25.0 892 ○ ◎ ◎ ◎ ○ ○

EM834 CARBIDE, 6&8 FLUTE 45° HELIX EXTRA LONG LENGTH ◇ D6.0 D25.0 892 ○ ◎ ◎ ◎ ○ ○

EM835 CARBIDE, 6 FLUTE 45° HELIX LONG LENGTH CORNER RADIUS ◇ D6.0 D20.0 893 ○ ◎ ◎ ◎ ○ ○

EM897 CARBIDE, 6 FLUTE 45° HELIX STUB CUT LENGTH ◇ D6.0 D12.0 894 ○ ◎ ◎ ◎ ○ ○
CORNER RADIUS
EM876 CARBIDE, 2 FLUTE SHORT LENGTH BALL NOSE ◇ R0.5 R12.5 895 ○ ◎ ◎ ◎ ○ ○ ○

EM813
EM823 CARBIDE, 2 FLUTE LONG LENGTH BALL NOSE ◇ R0.5 R12.5 896 ○ ◎ ◎ ◎ ○ ○ ○
EM815 CARBIDE, 4 FLUTE LONG LENGTH BALL NOSE
EM825 ◇ R0.5 R12.5 896 ○ ◎ ◎ ◎ ○ ○ ○
◇ Call for Availability
