I N DUS T R I A L A U T O M A TI O N & P R O C E S S C O NTRO L C A B L E S 117

CSA Control Cable
600V ACIC and TECK 90 Cables — Overview

Belden TECK 90 and ACIC cables are designed Construction Design Advantages Industrial Cable
®
to meet demanding industrial needs by
Class B stranded bare copper conductors,
combining rugged durability and corrosion insulation Properties
cross-link polyethylene insulation, bare
resistance with flexibility and easy handling. • High tensile strength
copper ground wire, PVC inner jacket,
aluminum steel interlocking armor, • Impact- and crush-resistant
PVC outer jacket. • Heat-resistant
• Galvanized steel interlocking armor • Excellent elongation
available as an option.
• Moisture-resistant
Voltage Rating • Good low temperature properties
Rip Cord
18 to 16 AWG — 600V ACIC
PVC Inner Jacket Electrical Properties
14 to 8 AWG — 600V
Interlocked Armor • High insulation resistance
PVC Outer Jacket XLP Insulation 14 to 4/0 AWG — 1000V • Low dielectric loss
• High dielectric strength
Temperature Rating
Introduction
Other Features
-40°C to 90°C (Dry/Wet)
TECK 90 and ACIC Cables are available
• Corrosion-resistant
in a wide range of standard and custom -25°C installed
constructions to meet the needs of oil • Versatile and flexible
and gas, pulp and paper, chemical, Application • Provides cost savings as conduit and
petroleum and other demanding industrial TECK 90 and ACIC are general-purpose ducts are not required
and resource industry environments. cables used in the oil and gas, pulp and • ACIC has a blue jacket
They are ideal for use in wet or dry areas, paper, mining, petroleum and chemical
ventilated or non-ventilated, ladder-type industries as well as in commercial buildings. • Rip cord for inner jacket
cable troughs, flexible cableways and Specifications
TECK 90 and ACIC may be used under the
direct burial installations.
following conditions: • CSA Standard C22.2 No. 131
Belden TECK 90 Cable is marked with “FT4,”
• Exposed or concealed wiring in dry or • CSA Standard C22.2 No. 174
“HL” designations, and cable constructions
wet conditions “Cables and Cable Glands for
are certified to CSA Standard C22.2 No. 131 Use in Hazardous Locations”
and C22.2 No. 174 for use in a wide range • In ventilated, non-ventilated or ladder-type
cable trays in dry or wet conditions • CSA Standard C22.2 No. 0.3 Clause 4.31
of hazardous locations. Both inner and “Low Acid Gas”
outer jackets meet the acid gas evolution • On walls or beams
• CSA Standard C22.2 No. 0.3 Clause 4.11.4
requirement of 14% maximum required by • Directly buried “Cables with FT4 Marking”
CSA Standard C22.2 No. 0.3 Clause 4.31.
• CEC Class I, Division I locations
Custom cables are available upon request.
Minimum Bending Radius
12 times the overall cable diameter
Pulling Tensions
The combined use of Kellems grips and
pulling eyes is recommended.

PVC = Polyvinyl Chloride • XLP = Cross-Linked Poly
