I N DUS T R I A L A U T O M A TI O N & P R O C E S S C O NTRO L C A B L E S 99

UL Control Cable
®
600V Type MC Metal Clad and Teck-Style Cables
Overview
Metal Clad Construction Design Advantages Industrial Cable
Class B stranded bare copper conductors, Insulation Properties
XLP insulation, bare copper ground wire,
• High tensile strength
standard aluminum or optional galvanized
steel interlocking armor, PVC outer jacket. • Impact- and crush-resistant
• Thermoset insulation — • Heat-resistant
Polyester Wrap XHHW-2 conductors • Excellent elongation
Interlocked Armor • NEC conductor temperature • Moisture-resistant
XLP Insulation 90°C dry and 90°C wet
PVC Outer Jacket • Good low temperature properties
Voltage Rating • 90°C dry and 90°C wet
Teck-Style
14 AWG — 2 AWG: 600 Volt
Electrical Properties
Application • High insulation resistance
Type MC Cable is a general-purpose • Low dielectric loss
cable used in the pulp and paper, mining, • High dielectric strength
petroleum and chemical industries as
Inner Jacket well as in commercial buildings. Other Features
Interlocked Armor MC Cable may be used under the • Corrosion-resistant
XLP Insulation
PVC Outer Jacket following conditions: • Versatile and flexible
• Exposed or concealed wiring in dry or • Provides cost savings as conduit
wet conditions and ducts are not required
Introduction
• In ventilated, non-ventilated or ladder-type Specifications
Belden® Metal Clad (MC) and Teck-Style cable trays in dry or wet conditions
cables are designed to meet demanding • UL 44
• On walls or beams
industrial needs by combining rugged • UL 1569
• Directly buried
durability and corrosion resistance with
• UL 1685 (UL 1581) Vertical Tray Flame Test
flexibility and easy handling. • Class I and II Div. 2 and Class III Div. 1 and (70,000 BTU/hr)
2 hazardous locations
MC and Teck-Style cables are available in a Teck-Style CSA Specifications
wide range of constructions for installation Minimum Bending Radius
in demanding industrial environments • CSA C22.2 No. 131
12 times the overall cable diameter
including oil and gas, mining, utility, • FT4 Flame Test
chemical, pulp and paper, and others. Pulling Tensions • HAZ LOC
They are ideal for use in wet or dry areas,
The combined use of Kellems grips and • CSA C22.2 No. 0.3 Clause 4.31
ventilated or non-ventilated, ladder-type
pulling eyes is recommended. Low Acid Gas
cable troughs and flexible cableways.
Custom cables are available to meet
exacting requirements.
Belden Type MC Cable is sunlight-resistant
and appropriate for outdoor use, installation
in cable trays, and direct burial.
Teck-Style cables are price-competitive,
high-performance, UL and CSA dual-rated
cables with a flame-retardant XHHW
insulated conductor and an inner PVC
jacket for mechanical moisture and
corrosion protection.

PVC = Polyvinyl Chloride • XLP = Cross-Linked Poly
