Page 33 - 2017 Product Guide

UNDERFLOOR HEATING | THERMOFOIL PRO

Econosoft Acoustic Barrier

Econosoft acoustic barrier (5422) should be
used with every Thermofoil PRO installation.
ACOUSTICS AND The Econosoft layer provides cushioning for
CUSHIONING
the heating cables and acts as an abrasion
layer to protect the heating elements from any
wear that could be caused by movement in a
floating floor build up.

Econosoft also has acoustic properties and the
cushioning layer will reduce impact sound by
as much as 21dB when used with a suitable
underlay such as our rigid insulation board
(5400).

Acoustic floors

FULL PROTECTIVE
EARTH BRAID

When an acoustic insulation layer is installed
below the floor finish, impact sound is absorbed
and noise pollution is greatly reduced.
Rigid insulation board

ACCESSIBLE CABLE
LOOPS FOR EASY
INSTALLATION

Thermofoil™ PRO Accessories Choose your thermostat on Pg. 42 - 48
STOCK DESCRIPTION UNIT RRP EXCL RRP INCL
NO $ $ Every Thermofoil PRO installation should
5400 Rigid Insulation Board (1200 x 500 x 5mm) 6m 2 90.00 99.00 include a layer of rigid insulation board
5415 Vapour Barrier 20m 2 71.82 79.00 (5400) under the heating element. This layer
acts as a 5mm cushion under the heating
5418 Fixing Tape 50Lm 26.36 29.00 element to protect it from any damage that
5422 Econosoft Acoustic Barrier 15m x 1m 308.18 339.00 could be caused by moving over the substrate.

5676 Aluminium Tape 50mm x 50m 44.55 49.00 Vapour Barrier

Vapour Barrier is an alternative for Econosoft
Acoustic Barrier that prevents the heating
from draining the moisture out of the floor. It
also acts as an abrasion layer, however does
not have any acoustic properties.

FREE DELIVERY ON ALL ORDERS OVER $250.00 RRP E&OE ©THERMOGROUP 33
