UNDERFLOOR HEATING | THERMOSCREED

In screed Heating Systems
In screed heating systems are extremely
versatile in their application as they are suitable
for use with any floor covering. Putting a screed
over the heating system before tiling also
ensures there is minimal risk of damage and a
flat surface onto which the floor finish can be
installed.
Now Available in Loose Wire and
Matting Systems!
Thermogroup now has both a loose wire and
matting system that is designed for use in
screeds of between 20-50mm thick. The loose
wire screed cable can be installed in multiple
ways (See diagrams below) and is ideal for
small and awkward areas or when wanting
to achieve a greater heat output. The matting
system however ensures an even cable spacing
and heat output and fast installation using the
simple cut and return process.
In Screed Accessories

Both the loose wire and matting systems require the addition of both the Edge Insulation Strip and a Thermostat (See page 42 - 48).
The matting system is very quick and easy to install on any substrate due to the self-adhesive mesh however the loose wire system requires additional
accessories in order to fix the heating cable to the floor – see options below.

Edge Insulation Strip Galvanised Fixing Profile
All screeds will expand and contract with changes in temperature The steel fixing profile is mechanically fixed to your substrate and
and therefore it is recommended that the edge insulation strip is cable is held in place with the easy to use cable clips over the area
installed around the perimeter of the room and around any fixtures that you want heated. The cables should be equally spaced across
to allow for the expansion and contraction of the screed. Required the substrate and run from end to end.
for both matting and loose wire systems.

3225 3259

In Screed Fixing for Waterproof Substrates
Thermogroup provides two fixing options for adhering the loose wire, in screed heating system to waterproofed substrates as the waterproofing cannot
be penetrated by any mechanical fixing methods (Such as the Galvanised Fixing Profile). The self-adhesive In Screed matting system can be stuck
directly to the waterproofing.
In Screed Cable Mesh Vario Ply Grid
In Screed Cable Mesh is designed to be simply loose laid over the Vario Ply Grid is a 600mm square connecting grid system which
substrate or waterproofing. The heating cable is then laid over loose lays over the waterproofing. The heating cable simply clips
the mesh and secured using strands of the mesh twisted over the into the grid providing a quick and easy installation.
cable.

3261 109550
