Page 37 - 2017 Product Guide

UNDERFLOOR HEATING | IN SCREED MATS

Quality Electric Underfloor Heating

In Screed Matting System
Comfortzone 200W Electric Matting System is
designed to be installed in a screed of between
NEW 20-50mm thick.
IN SCREED When installed under a 20-50mm screed
MATTING Comfortzone 200W can be covered by any floor
SYSTEM finish.

1
2
3
4
5

1 Floor tiles
2 Sand & cement screed
Comfortzone 200W/M² Matting System 3 Comfortzone 200W system
STOCK SIZE AREA OUTPUT RRP EXCL RRP INCL 4 Econoboard Coated Insulation
NO M M2 W $ $ 5 Timber Substrate
118550 2 x 0.5 1.0 200 144.55 159.00
118552 3 x 0.5 1.5 300 153.64 169.00
118554 4 x 0.5 2.0 400 190.91 210.00 1
118556 5 x 0.5 2.5 500 217.27 239.00 2
3
118558 6 x 0.5 3.0 600 290.00 319.00
4
118560 8 x 0.5 4.0 800 371.82 409.00
5
118562 10 x 0.5 5.0 1000 426.36 469.00 6
118564 12 x 0.5 6.0 1200 562.73 619.00
118566 16 x 0.5 8.0 1600 753.64 829.00
1 Floor tiles
118568 20 x 0.5 10.0 2000 835.45 919.00
2 Sand & cement screed
118570 24 x 0.5 12.0 2400 1,126.36 1,239.00
3 Comfortzone 200W system
4 Econoboard Uncoated Insulation
Comfortzone 200W Accessories Choose your thermostat on Pg. 42 - 48 5 Flexible Tile Adhesive
6 Concrete Substrate
STOCK DESCRIPTION UNIT RRP EXCL RRP INCL
NO $ $
3225 Edge Insulation Strip 50m x 80mm x 8mm roll 126.36 139.00

LAY WIRE !
SIDE DOWN

Roll out the heating mat and adhere to insulation or When you reach the wall, cut the mesh, turn the mat, and
substrate. begin rolling in the desired direction.

FREE DELIVERY ON ALL ORDERS OVER $250.00 RRP E&OE ©THERMOGROUP 37
