Page 104 - Catalogue IML-VP 2024
P. 104
PUMPS AND COUNTER CURRENT SWIMMING
SERIE
BIG DISCOVERY
SELF-PRIMING PUMP
BOMBA AUTOASPIRANTE
Bush connections included with the pump.
Manguitos incluidos con la bomba.
L
E G
PALLET: 12 u.
ØD 124 × 84 × 150 cm
BOX: 1 u.
84 × 30 × 45 cm
150
H ØC
A F
B 45
30 84
124
84
CODE POWER DIMENSIONS WEIGHT VOLUME
kW CV A B C D E F G H L kg m3
DY350T-M 2,2 3,0 300 160 Ø90 Ø75 368 320 264 431 713 24 0,12
DY400T-M 2,9 4,0 300 160 Ø90 Ø75 368 320 264 431 713 27 0,12
DY550T-M 4,0 5,5 300 160 Ø90 Ø75 368 320 264 431 713 29 0,12
