DEHUMIDIFICATION EQUIPMENT

STORM

DEHUMIDIFIER
DÉSHUMIDIFICATEUR

590PCF22BD, 590PCF43BD 590PCF22WD, 590PCF43WD

DEHUMIDITY
OPERATING AIR
VENTILATOR FOR POOL WATER LITRES/DAY
CODE TYPE COLOUR INSTALLATION TEMPERATURE
m³/h SURFACE m2 (AIR 30 °C,
°C
RH 70 %)
590PCF22BD STORM 50 450 black 42 10–36 53
590PCF43BD STORM 100 700 black 83 10–36 103
on the wall /
on the floor
590PCF22WD STORM W 50 450 white 42 10–36 53
590PCF43WD STORM W 100 700 white 83 10–36 103

RATED MAX. MAX. NOISE INLET WEIGHT
POWER VOLUME
CODE TYPE INPUT INPUT CURRENT LEVEL OUTLET GROSS
SUPPLY m3
kW kW kW dB air kg
590PCF22BD STORM 50 230 V 0,93 1,02 4,30 44 70,0 –
590PCF43BD STORM 100 230 V 1,97 2,28 10,0 48 84,0 –
bottom
top
590PCF22WD STORM W 50 230 V 0,93 1,02 4,30 44 70,0 –
590PCF43WD STORM W 100 230 V 1,97 2,28 10,0 48 84,0 –
