POOL BASIN EQUIPMENT
NOZZLE STAINLESS STEEL VAMILA – ACCESSORIES
PASAMUROS
3575 31190 31191 30705 30702
WEIGHT
CODE DESCRIPTION PACKING GROSS
kg
3575 Flange set VAMILA for suction for liner (using pool wall lead-through) 1 0,10
31190 Poolwall lead-through stainless steel R 2“, length 300 mm 1 0,20
31191 Poolwall lead-through for liner stainless steel R 2“, length 300 mm 1 1,20
30705 Stainless steel nozzle frame VAMILA – square 1 0,50
30702 Assembly spanner for VAMILA stainless. steel – universal 1 0,30
POOL WALL LEAD-THROUGH
with brass inserts
Ø95 ø95
Ø83 ø83
G2" G2"
ø120 50 50
ø95
ø83 36125
G2" 300 300
50
150
25
31
ø63 38
ø50 ø50 ø75
ø63 ø63
x 6 B o h 120
r u n g ø 3 120 6 x Bohrung Ø3,5, 10 mm tief 6 x Bohrung ø3,5, 10mm tief
, , 5 1 0
m
126
m
i t
126
e
f
31125 3113 3114
WEIGHT
CODE DESCRIPTION PACKING GROSS
kg
31125 Pool wall lead-through R 2“, to connect with glue 50 mm, 63 mm, length 150 mm 40 0,15
36125 Pool wall lead-through R 2“ with brass inserts, to connect with glue 50 mm, 63 mm, length 150 mm 40 0,15
3113 P ool wall lead-through R 2“, to connect with glue 50 mm, 63 mm, length 300 mm 35 0,19
3114 Pool wall lead-through R 2“, to connect with glue 63 mm, 75 mm, length 300 mm 35 0,40
