POOL BASIN EQUIPMENT
SUCTION FOR OVERFLOW CHANNEL
EN ES
Made of white ABS. Fabricado en ABS blanco.
Dimensions 142 mm x 69 mm. Dimensiones 142 mm x 69 mm.
Rectangle grating fixed with stainless steel Rejilla rectangular fijada con tornillos de
screws. acero inoxidable.
Connection with glue Ø63 mm. Conexión para encolado de Ø63 mm.
Flow capacity 9 m³/h. Capacidad de caudal 9 m³/h.
00302
DIMENSIONS WEIGHT VOLUME
CODE DESCRIPTION PACK. GROSS m3
A B C D kg
00302 Suction for overflow channel, connection 63 mm – – – – 1 0,20 –
PUBLIC POOL NORM MAIN DRAINS
EN ES
AISI 316 grating, ABS body. Rejilla AISI 316, cuerpo de ABS.
Connection with glue Ø63 mm int./2½“ ext. Conexión para encolado de Ø63 mm int.
y 2½“ ext.
313194 313194
WEIGHT
CODE POOL DESCRIPTION PACK. GROSS VOLUME
kg m3
313194 Suction VAMILA st. steel, 30 m³/h 1 1,15 –
PREFABR./
313196 LINER Suction VAMILA st. steel, connection glue Ø63 mm int./2½“ ext., 1 0,30 –
30 m³/h – thin grating
313195 Suction VAMILA st. steel, 30 m³/h 1 0,95 –
CONCRETE
313197 HORMIGÓN Suction VAMILA st. steel, connection glue Ø63 mm int./2½“ ext., 1 0,95 –
30 m³/h – thin grating
