PUMPS AND COUNTER CURRENT SWIMMING
S
C
TERS AND SELE
AND FIL
COMPACT FILTRATION EN Compact filtration method permits easy
installation of filter, pump and selector valve.
NOTE: For full details and characteristics of our
filters, pumps, valves and other accessories,
please contact the factory.
HOUSING ES Compacto técnico de filtración para instalación
de filtro, bomba y válvula selectora.
NOTA: Para detalles y características de los fil-
tros, las bombas, las válvulas y otros accesorios,
CASETAS DE FILTRACIÓN contactar con fábrica.
LOCAUX TECHNIQUES

CS030619 - CS030620
CS030615 - CS030616 - CS030617 -
CS030618

CS030621
CS032771

DIMENSIONS WEIGHT
FILTER VOLUME
CODE TYPE PACKING GROSS
Ø m3
A B C D E kg
CS030615 in-ground / enterrada 350 900 650 730 70 620 1 35 0,77

CS030616 in-ground / enterrada 400 - 600 1000 1000 900 70 725 1 43 1,16

CS030617 in-ground / enterrada 650 1200 1000 925 70 740 1 88 1,43
CS030618 in-ground / enterrada 650 - 800 1500 1200 1220 70 1035 1 125 2,32

CS032771 in-ground / enterrada 900 - 950 1235 1800 1290 – – 1 170 4,36

CS030619 semi-in-ground / semienterrada 450 - 600 1040 870 525 500 270 1 40 1,55

CS030620 semi-in-ground / semienterrada 600 - 750 1350 1200 675 470 500 1 73 1,55

CS030621 semi-in-ground / semienterrada 600 1230 1230 540 535 430 1 65 2,52

83
