f Software: For structural detailing, the most sophisticated ‘Tekla’ software was used.
f Design life: Design life of the bridge is expected to be 120 years.

f Wind tolerance: Bridge is designed to withstand high wind speed up to 266 Km/Hour.
f Blast load: Bridge is designed for blast load in consultation with DRDO for the first time in India.
f Seismic tolerance: It is designed to bear earthquake forces of highest intensity zone-V in India.
f Testing: First time on Indian Railways, Phased Array Ultrasonic Testing machine is used for testing of
welds.

f Welding: First time on Indian Railways, NABL accredited lab is established at site for weld testing.
Approx. 584Km welding is done to join the different parts of the structure, which is to the tune of distance
between Jammu Tawi to New Delhi.

f Design: Heightof the cable crane’s pylon at Srinagar end is 127m, which is much taller than Qutub Minar
of 72m. Launch of curved viaduct portion is done for first time on Indian Railways using End Launching
Method.

f Warning system: Extensive health monitoring and warningsystems planned through state of art
instrumentation.

CHENAB RIVER
The Chenab is formed by the confluence of two
streams, Chandra and Bhaga, in the western
Himalayas in Himachal Pradesh. It flows west
through Jammu and Kashmir between the steep cliffs
of the Siwalik Range (south) and the Lesser
Himalayas (north). Turning southwest, it continues
into Pakistan, descending from the uplands into the
broad alluvial lowlands of Punjab province. After
receiving the Jhelum River near Trimmu, the Chenab
empties into the Sutlej River, a tributary of the Indus
River. Its total length is about 974 km, and it feeds several irrigation canals.
