WK Solid carbide twist drills for aluminum

5xD Maximal hole depth AL

VHM

TB

0
DIN 130
6537

P P P M M M K K K P M K
Material groups
N N N S S S H H H N S H
IK
Internal cooling IK IK
Quality of material VHM VHM
Coating - TB
Nakrój / Chamfer Norm DIN-6537
VHM
Ć d M M MF l 1 l 2 Ćd h6 Tol. m7 m7
1 MF "WGN" 2
INDEX W9-611733 W9-61B733

3,00 66 28 6,0 0300
3,10 66 28 6,0 0310
3,20 66 28 6,0 0320
6 3,25 M4 M3,5 66 28 6,0 0325
28
66
3,30
6,0
0330
3,40
28
6,0
3,50 M4x0,5 66 28 6,0 0340
66
0350
3,60 66 28 6,0 0360
3,70 M4,5 M4 66 28 6,0 0370
3,80 74 36 6,0 0380
3,90 74 36 6,0 0390
4,00 74 36 6,0 0400
4,10 74 36 6,0 0410
4,20 M5 M4,5 74 36 6,0 0420
4,30 74 36 6,0 0430
4,40 74 36 6,0 0440
4,50 M5x0,5 74 36 6,0 0450
74
36
6,0
4,60
7 4,65 M5 74 36 6,0 0460
M5,5
0465
36
4,70
74
6,0
0470
4,80 82 44 6,0 0480
4,90 82 44 6,0 0490
5,00 M6 82 44 6,0 0500
5,10 M5,5 82 44 6,0 0510
5,20 M6x0,75 82 44 6,0 0520
5,30 82 44 6,0 0530
5,40 82 44 6,0 0540
5,50 82 44 6,0 0550
5,60 M6 82 44 6,0 0560
5,70 82 44 6,0 0570
5,80 82 44 6,0 0580
5,90 82 44 6,0 0590
6,00 M7 82 44 6,0 0600
6,10 91 53 8,0 0610
6,20 M7x0,75 91 53 8,0 0620
6,30 91 53 8,0 0630
6,40 91 53 8,0 0640
6,50 91 53 8,0 0650
6,60 M7 91 53 8,0 0660
6,70 91 53 8,0 0670
6,80 M8 91 53 8,0 0680
6,90 91 53 8,0 0690
7,00 M8x1 91 53 8,0 0700
7,10 91 53 8,0 0710
7,20 M8x0,75 91 53 8,0 0720
7,30 91 53 8,0 0730
Example of order Available from stock
142
W9-611733-0300 On request
WK AL 3,00 DIN-6537 VHM TB
