Countersinks WK

PF

INDEX

25,5 1 T9-100013-0400
20,5 2 T9-100012-0560
14,5 2 T9-100011-0720

Accessories Processing parameters P M K
Material groups
N S H
Designation INDEX Material n (1/min) feed f (mm/tooth)
Internal cooling IK
Quality of material
Insert AH 330 T9-104000-0127 Carbon steel VHM
Clamping screw T9-100001-0000 Superalloys
Coating
Key T9-100002-0000 Tool steel AT
Nakrój / Chamfer Stainless
Cast iron
Z-axis plunging depth Z (mm)
- For the phase 30° - For the phase 45°
hole dia. Size of chamfering C (mm) hole dia. Size of chamfering C (mm)
Ćd (mm) Ćd (mm) 6 6

7

- For the phase 60°
hole dia. Size of chamfering C (mm)
Ćd (mm)

Note:
When the hole depth is smaller
than the Z-axis plunging
depth (Zd), special care should be
taken to avoid an interference
between the tool's front end and
the bottom of the hole.

Technical informations
• When the hole diameter to be chamfered is small or the cutting edges near the front end of tool are used, use at higher side of the revolution
range shown in the Table. In contrast, when the hole diameter to be chamfered is large or the cutting edges far from the tool's front end are used,
use the lower side of the revolution range shown in the Table.
• When chamfering a small diameter hole (smaller than ø10 mm) in a plungemilling mode, peck-feeding should not be used.
• When the hole diameter to be chamfered is smaller than ø10 mm or the cutting edges near the tool's front end are used, the feed should
be set within 0.15 mm/t.
Example of order Available from stock 155
T9-100013-0400 On request
Countersinks 40
