Page 154 - Fanar

WK Center drills NC

For spot and chamfering thread holes in one operation

VHM

TN2

HSSE

P P M M K K P M K P M K P M K
Material groups
N N S S H H N S H N S H N S H
-
Internal cooling IK - - -
Quality of material HSSE HSSE HSSE VHM
Coating - TN2 TN2 -
Nakrój / Chamfer 90° 90° 120° 142°
Point angle
VHM
δ90 / δ120° δ142° Norm
Ć d Tol.
1
l 1 l 2 l 1 l 2
INDEX W2-001012 W2-003012 W2-003013 W9-001014
3,0 46 12 45 12,0 0300
6 4,0 55 12 50 15,0 0400
15
62
0500
50
5,0
18,0
66
21,0
0600
20
50
6,0
8,0 79 25 60 25,0 0800
10,0 89 25 70 27,0 0100
12,0 102 30 70 27,0 0120
14,0 107 34 75 30,0 0140
16,0 115 35 75 30,0 0160
7

Example of order Available from stock
150
W2-001012-0300 On request
Center drills NC 3,00 HSSE TN 2
