Tr Thread gauges plug and ring TR
Trapezoidal thread Tr, DIN-103
30 o
Gauge dimensions DIN 103-9
Symbol MSBg MSRh MSRk
Type GO / NOGO GO NOGO
Tolerance Tr Tol 7H 7e 7e
P
Ć d [mm] [mm]
1 INDEX S3-302171 Y3-412174 Y3-422174
Tr 10 x 2 2 8009
Tr 12 x 3 3 8015
Tr 14 x 3 3 8019
Tr 16 x 4 4 8024
Tr 18 x 4 4 8032
Tr 20 x 4 4 8034
Tr 22 x 5 5 8037
Tr 24 x 5 5 8042
Tr 26 x 5 5 8047
Tr 28 x 5 5 8052
7
Tr 30 x 6 6 8057 6
Tr 32 x 6 6 8062
Tr 36 x 6 6 8072
Example of order Available from stock 173
S3-302171-8009 On request
MSBg Tr 10x2-7H
