Page 413 - Deko-Light Light Impressions 2019-20
P. 413
POWER SPOT COB IV WW
aluminium diecast
dimensions L x W x Ø: 87 x 100 x 100 mm
power input: 6,20 W
energy efficiency class [EEI] spectrum A ++ to E
730190 anthracite WW 2300 K 360 lm EEI: A
220-240 4,50 W COB 1 Ra>80 30° IP65/
LED IP44
accessories
700229 ground spike black | plastic | 160 mm
suitable outdoor mounting material from page 783
POWER SPOT
aluminium diecast
dimensions L x W x H x Ø: 112 x 110 x 35 x 90 mm
dimmable via optional controller
power input: 5,50 W
energy efficiency class [EEI] spectrum A ++ to E
730277 anthracite WW 3000 K 390 lm EEI: A+
730280 anthracite CW 6500 K 480 lm EEI: A++
24 3
5,50 W LED Ra>80 20° 90° IP65
accessories
872041 power supply | 24V | 12 W | IP65
872618 power supply | 24V | 36 W | IP67
843022 RF Single controller dimmable | 12 - 24V DC | max. 360 W
843336 DMX LED dimmer 2 dimmable | 12 - 24V DC
843010 DALI 4 channel PWM dimmer | 12 - 24V DC
suitable dimmers and controllers from page 692
suitable Weipu cable systems from page 772
suitable outdoor mounting material from page 783
412 OUTDOOR LAMPS | surface mounted spotlight
