Page 418 - Deko-Light Light Impressions 2019-20
P. 418
CEPHEI
aluminium diecast
dimensions L x W x H x Ø: 197 x 177 x 54 x 158 mm
dimmable via optional controller
power input: 23,30 W
energy efficiency class [EEI] spectrum A ++ to E
732062 anthracite RGB 550 lm EEI: A
24 23,30 W 6 30° 3 CH IP65
LED
accessories
872658 power supply | 24V | 36 W | IP20
872618 power supply | 24V | 36 W | IP67
843024 RF colour remote controller dimmable | 12-24V DC | max. 360 W
843335 DMX LED dimmer 3 dimmable | 12 - 24V DC
843010 DALI 4 channel PWM dimmer | 12 - 24V DC
suitable dimmers and controllers from page 692
suitable Weipu cable systems from page 772
suitable outdoor mounting material from page 783
POWER SPOT I RGBWW
aluminium diecast
dimensions L x W x H x Ø: 177 x 146 x 197 x 158 mm
dimmable via optional controller
power input: 33,00 W
energy efficiency class [EEI] spectrum A ++ to E
732078 anthracite RGB WW 3000 K 900 lm EEI: A
24 5
33 W SMD LED 30° 4 CH IP65
accessories
872658 power supply | 24V | 36 W | IP20
872618 power supply | 24V | 36 W | IP67
843025 RF controller RGB+W dimmable | 12 - 24V DC | max. 360 W
843337 DMX LED dimmer 4 dimmable | 12 - 24V DC
843010 DALI 4 channel PWM dimmer | 12 - 24V DC
suitable dimmers and controllers from page 692
suitable Weipu cable systems from page 772
suitable outdoor mounting material from page 783
OUTDOOR LAMPS | surface mounted spotlight 417
