Page 417 - Deko-Light Light Impressions 2019-20
P. 417
POWER SPOT VI RGB
aluminium diecast
dimensions L x W x H x Ø: 263 x 177 x 89 x 158 mm
socket H x Ø: 48 x 120 mm
dimmable via optional controller
power input: 25,00 W
energy efficiency class [EEI] spectrum A ++ to E
730293 anthracite RGB 540 lm EEI: A
24 25 W 6 30° 3 CH IP65
LED
accessories
872658 power supply | 24V | 36 W | IP20
872618 power supply | 24V | 36 W | IP67
843024 RF colour remote controller dimmable | 12-24V DC | max. 360 W
843335 DMX LED dimmer 3 dimmable | 12 - 24V DC
843010 DALI 4 channel PWM dimmer | 12 - 24V DC
suitable dimmers and controllers from page 692
suitable Weipu cable systems from page 772
CARINAE
aluminium diecast
dimensions L x W x H x Ø: 220 x 151 x 75 x 130 mm
socket H x Ø: 48 x 120 mm
dimmable via optional controller
power input: 16,90 W
energy efficiency class [EEI] spectrum A ++ to E
732063 anthracite RGB 520 lm EEI: A
24 6
16,90 W LED 30° 3 CH IP65
accessories
872658 power supply | 24V | 36 W | IP20
872618 power supply | 24V | 36 W | IP67
843024 RF colour remote controller dimmable | 12-24V DC | max. 360 W
843335 DMX LED dimmer 3 dimmable | 12 - 24V DC
843010 DALI 4 channel PWM dimmer | 12 - 24V DC
suitable dimmers and controllers from page 692
suitable Weipu cable systems from page 772
suitable outdoor mounting material from page 783
416 OUTDOOR LAMPS | surface mounted spotlight
