Page 414 - Deko-Light Light Impressions 2019-20
P. 414
POWER SPOT II WW
aluminium diecast
dimensions L x W x H x Ø: 163 x 151 x 49 x 130 mm
dimmable via optional controller
power input: 13,80 W
energy efficiency class [EEI] spectrum A ++ to E
730279 anthracite WW 3000 K 880 lm EEI: A
730278 anthracite CW 6000 K 1020 lm EEI: A+
24 13,80 W 6 Ra>80 20° IP65
LED
accessories
872058 power supply | 24V | 18 W
872618 power supply | 24V | 36 W
843022 RF Single controller dimmable | 12 - 24V DC | max. 360 W
843336 LED dimmer 2 dimmable | 12 - 24V DC
843010 DALI 4 channel PWM dimmer | 12 - 24V DC
suitable dimmers and controllers from page 692
suitable Weipu cable systems from page 772
suitable outdoor mounting material from page 783
POWER SPOT II RGB
aluminium diecast
dimensions L x W x H x Ø: 163 x 151 x 48 x 130 mm
dimmable via optional controller
power input: 17,00 W
energy efficiency class [EEI] spectrum A ++ to E
730295 anthracite RGB 500 lm EEI: A
24 6
17 W SMD LED 30° 3 CH IP65
accessories
872058 power supply | 24V | 18 W
872636 power supply | 24V | 20 W
843022 RF Single controller dimmable | 12 - 24V DC | max. 360 W
843335 LED dimmer 3 dimmable | 12 - 24V DC | 60 W
843010 DALI 4 channel PWM dimmer | 12 - 24V DC
suitable dimmers and controllers from page 692
suitable Weipu cable systems from page 772
suitable outdoor mounting material from page 783
OUTDOOR LAMPS | surface mounted spotlight 413
