Page 468 - Deko-Light Light Impressions 2019-20
P. 468
LINE II WWA
stainless steel
dimensions L x W x H: 328 x 63 x 65 mm
asymmetric
dimmable via optional controller
power input: 12,20 W
energy efficiency class [EEI] spectrum A ++ to E
730008 silver coloured WW 3000 K 750 lm EEI: A
6
CV 24 12,20 W LED Ra>80 45°/35° 313x58 90 IP67
accessories
872618 power supply | 24V DC | 36 W | IP67
843022 RF single controller dimmable | 12 - 24V DC | max. 360 W
843336 DMX LED dimmer 2 dimmable | 12 - 24V DC
843010 DALI 4 channel PWM dimmer | 12 - 24V DC
suitable dimmers and controllers from page 692
suitable Weipu cable systems from page 772
LINE III RGB
stainless steel
dimensions L x W x H: 328 x 63 x 65 mm
dimmable via optional controller
power input: 16,50 W
energy efficiency class [EEI] spectrum A ++ to E
730263 silver coloured RGB 400 lm EEI: A
24 6
CV 16,50 W SMD LED 35° 313x58 90 IP67
accessories
872618 power supply | 24V DC | 36 W | IP67
843022 RF single controller dimmable | 12 - 24V DC | max. 360 W
843336 DMX LED dimmer 2 dimmable | 12 - 24V DC
843010 DALI 4 channel PWM dimmer | 12 - 24V DC
suitable dimmers and controllers from page 692
suitable Weipu cable systems from page 772
OUTDOOR LAMPS | ground built-in lamps 467
