Page 472 - Deko-Light Light Impressions 2019-20
P. 472
SAGITTAE LED PROFILE COMPLETE SET IP67
material: aluminium
connection stripe: 2 cable [V-, V+]
incl. 1m connection cable with WEIPU-plug
dimmable via optional controller
730451 3000 K 96 LEDs 5,3 W 190 lm 1000 x 27 x 30 mm EEI: A
730452 3000 K 192 LEDs 18 W 340 lm 2000 x 27 x 30 mm EEI: A
connection stripe: 5 cable [R, G, B, W, V+]
730453 3000 K | 460 - 620 nm 192 LEDs 22 W 190 lm 1000 x 27 x 30 mm EEI: A
730456 3000 K | 450 - 630 nm 384 LEDs 42 W 340 lm 2000 x 27 x 30 mm EEI: A
24 SMD
3528 100° Ra>80 IP67
accessories
990109 foam support | 126 x 2,6 x 3 cm | plastic | hard foam
872658 power supply | 24V DC | 36 W | IP20
872660 power supply | 24V DC | 50 W | IP20
872618 power supply | 24V DC | 36 W | IP67
872619 power supply | 24V DC | 75 W | IP67
843022 RF single controller dimmable | 12 - 24V DC | max. 360 W
843025 RF colour+white dimmable | 12 - 24V DC
843010 DALI 4 channel PWM dimmer | 12 - 24V DC
suitable dimmers and controllers from page 692
suitable Weipu cable systems from page 772
OUTDOOR LAMPS | ground built-in lamps 471
