Page 469 - Deko-Light Light Impressions 2019-20
P. 469
LINE V WW
stainless steel
dimensions L x W x H: 549 x 68 x 31,5 mm
power input: 18,00 W
energy efficiency class [EEI] spectrum A ++ to E
730434 silver coloured WW 3000 K 1100 lm EEI: A
730435 silver coloured CW 6500 K 1300 lm EEI: A
220-240 12
16 W SMD LED Ra>80 20° 524x58 80 IP67
suitable outdoor mounting material from page 783
LINE V RGB
stainless steel
dimensions L x W x H: 549 x 68 x 32,5 mm
dimmable via optional controller
power input: 21,60 W
energy efficiency class [EEI] spectrum A ++ to E
730437 silver coloured RGB 340 lm EEI: B
CV 24 18 W 12 30° IP67
LED 524x58 80
accessories
872658 power supply | 24V DC | 36 W | IP20
872618 power supply | 24V DC | 36 W | IP67
843022 RF single controller dimmable | 12 - 24V DC | max. 360 W
843335 DMX LED dimmer 3 dimmable | 12 - 24V DC
843010 DALI 4 channel PWM dimmer | 12 - 24V DC
suitable dimmers and controllers from page 692
suitable Weipu cable systems from page 772
468 OUTDOOR LAMPS | ground built-in lamps
