Page 470 - Deko-Light Light Impressions 2019-20
P. 470
LINE VI WW
stainless steel
dimensions L x W x H: 1025 x 68 x 80 mm
power input: 36,00 W
energy efficiency class [EEI] spectrum A ++ to E
730432 silver coloured WW 3000 K 2300 lm EEI: A
730433 silver coloured CW 6500 K 2600 lm EEI: A
220-240 24
34 W COB LED Ra>80 20° 1004x58 80 IP67
suitable outdoor mounting material from page 783
LINE VI RGB
stainless steel
dimensions L x W x H: 1025 x 68 x 31,5 mm
dimmable via optional controller
power input: 42,80 W
energy efficiency class [EEI] spectrum A ++ to E
730436 silver coloured RGB 700 lm EEI: A
CV 24 42,80 W 24 30° IP67
LED 1004x58 80
accessories
872660 power supply | 24V DC | 50 W | IP20
872619 power supply | 24V DC | 75 W | IP67
843022 RF single controller dimmable | 12 - 24V DC | max. 360 W
843335 DMX LED dimmer 3 dimmable | 12 - 24V DC
843010 DALI 4 channel PWM dimmer | 12 - 24V DC
suitable dimmers and controllers from page 692
suitable Weipu cable systems from page 772
OUTDOOR LAMPS | ground built-in lamps 469
