P. 476

SHARK I RGB
              ‚ stainless steel
              ‚ dimensions H x Ø: 33 x 115 mm
              ‚ dimmable via optional controller
              ‚ power input: 15,00 W
              ‚ energy efficiency class [EEI] spectrum A ++ to E

           785017      silver coloured   RGB        400 lm EEI: A

                            6
             CV   24   15 W  LED  30°      3 CH  IP68

           accessories
           872045      power supply dimmable | 24V DC | 60 W
           872046      power supply dimmable | 24V DC | 150 W
           843024      RF colour remote | 12 - 24V DC | max. 360 W
           843335      DMX LED dimmer 3 dimmable | 12 - 24V DC
           843010      DALI PWM dimmer | 12 - 24V | max. 4 x 120 W
                       suitable dimmers and controllers from page 692
                       suitable Weipu cable systems from page 772









           WAVE II WW

              ‚ stainless steel
              ‚ dimensions H x Ø: 65 x 200 mm
              ‚ dimmable via optional controller
              ‚ power input: 30,00 W
              ‚ energy efficiency class [EEI] spectrum A ++ to E
           740002      silver coloured   WW  3000 K  1346 lm EEI: A
           740001      silver coloured   CW  6500 K  1600 lm EEI: A


             CV   24   30 W  12   Ra>80  25°     IP68
                            LED
           accessories
           872045      power supply dimmable | 24V DC | 60 W
           872046      power supply dimmable | 24V DC | 150 W
           843022      RF single controller dimmable | 12 - 24V DC | max. 360 W
           843336      DMX LED dimmer 2 dimmable | 12 - 24V DC
           843010      DALI PWM dimmer | 12 - 24V | max. 4 x 120 W
                       suitable dimmers and controllers from page 692
                       suitable Weipu cable systems from page 772
