Page 475 - Deko-Light Light Impressions 2019-20
P. 475
SNAPPER I WW
stainless steel
dimensions H x Ø: 73 x 68,5 mm
dimmable via optional controller
power input: 3,00 W
energy efficiency class [EEI] spectrum A ++ to E
131002 silver coloured WW 3000 K 150 lm EEI: A+
131001 silver coloured CW 5500 K 200 lm EEI: A++
1
CV 24 3 W LED Ra>80 45°/35° 59 135 IP68
accessories
872045 power supply dimmable | 24V DC | 60 W
872046 power supply dimmable | 24V DC | 150 W
843022 RF single controller dimmable | 12 - 24V DC | max. 360 W
843336 DMX LED dimmer 2 dimmable | 12 - 24V DC
843010 DALI PWM dimmer | 12 - 24V | max. 4 x 120 W
suitable dimmers and controllers from page 692
suitable Weipu cable systems from page 772
SHARK I WW
stainless steel
dimensions H x Ø: 33 x 115 mm
dimmable via optional controller
power input: 11,80 W
energy efficiency class [EEI] spectrum A ++ to E
785016 silver coloured WW 3000 K 770 lm EEI: A
785015 silver coloured CW 6000 K 1000 lm EEI: A+
CV 24 11,80 W 6 Ra>80 30° IP68
LED
accessories
872045 power supply dimmable | 24V DC | 60 W
872046 power supply dimmable | 24V DC | 150 W
843022 RF single controller dimmable | 12 - 24V DC | max. 360 W
843336 DMX LED dimmer 2 dimmable | 12 - 24V DC
843010 DALI PWM dimmer | 12 - 24V | max. 4 x 120 W
suitable dimmers and controllers from page 692
suitable Weipu cable systems from page 772
474 OUTDOOR LAMPS | underwater lamps
