P. 737
BASIC INFORMATION ON THE USE OF DALI BALLASTS
DALI SINGLE DIMMER DALI BUS READY
DALI single dimmers cannot be integrated into existing These components can be integrated and controlled in
DALI networks. The control takes place via so-called single existing DALI BUS systems that comply with the IEC 62386
dimmers, which generate their own control signal. protocol.
KAPEGO POWER SUPPLY | BAUFORM BASIC
DALI CC DRIVER
dimmable via DALI-single dimmer
862057 black 350mA 20W 2 - 58V 122 x 52 x 30 mm
220-240 20 M M
CC
KAPEGO POWER SUPPLY | DESIGN BASIC
MULTI-CURRENT
current range via DIP-switch adjustable
DALI BUS ready according to protocol IEC 62386
862147 white 350mA 14W 9 - 40V 150 x 42 x 28 mm
500mA 20W 9 - 40V
550mA 19,8W 9 - 36V
700mA 19,6W 9 - 28V
862144 white 550mA 24,7W 9 - 45V 150 x 42 x 28 mm
600mA 27W 9 - 45V
650mA 29W 9 - 45V
700mA 30,1W 9 - 43V
750mA 30W 9 - 40V
800mA 30,4W 9 - 38V
850mA 29,7W 9 - 35V
900mA 30,6W 9 - 34V
220-240 CC max 30 M M
736 POWER SUPPLY | DC | indoor | constant power | dimmable via DALI
