TCI POWER SUPPLY JOLLY US 32 | DIMMABLE
via 1-10V dimmable or touch dimmer-function [Push]
strom- [CC] or constant voltage [CV]
via DIP-switch adjustable
master/slave operation of several power supplies
via sync cable [accessories]
862007 white Jolly US 32 103 x 67 x 21 mm
constant power 350mA 15W 2 - 47V
500mA 24W 2 - 47V
550mA 25W 2 - 47V
700mA 32W 2 - 46V
850mA 20W 2 - 24V
900mA 20W 2 - 22V
constant voltage 10V 10W
12V 13W
24V 20W
220-240 max 32 M M
CV CC
accessories
561202 SYNC cable for synchronization of max. 10 power supplies
with push function, length 150 cm
TCI POWER SUPPLY JOLLY US 25 | DIMMABLE
via 1-10V dimmable
strom- [CC] or constant voltage [CV]
via DIP-switch adjustable
master/slave operation of several power supplies
via sync cable [accessories]
862015 white Jolly US 25 124 x 79 x 21 mm
constant power 350mA 25W 2 - 74V
500mA 35W 2 - 72V
550mA 39W 2 - 72V
650mA 46W 2 - 72V
700mA 50W 2 - 71V
750mA 50W 2 - 66V
850mA 50W 2 - 58V
900mA 50W 2 - 55V
1050mA 50W 2 - 48V
constant voltage 48V 50W
220-240 CV CC max 50 M M
accessories
561202 SYNC cable for synchronization of max. 10 power supplies
with push function, length 150 cm
MULTI-POWER SUPPLY | DC | indoor | strom- or constant voltage 741
