P. 739
MEANWELL DALI POWER SUPPLY LCM-DA SERIES | 25DA | 40DA | 60DA
current range via DIP-switch adjustable
DALI BUS ready according to protocol IEC 62386
dimmable via DALI or touch dimmer-function [Push]
master/slave operation of several power supplies
via sync cable [accessories]
862012 white 350mA 18,9W 6 - 54V 105 x 68 x 23 mm
500mA 25,2W 6 - 50V
600mA 25,2W 6 - 42V
700mA 25,2W 6 - 36V
900mA 25,2W 6 - 28V
1050mA 25,2W 6 - 24V
862013 white 350mA 42W 2 - 100V 124 x 82 x 23 mm
500mA 42W 2 - 80V
600mA 42W 2 - 67V
700mA 42W 2 - 57V
900mA 42W 2 - 45V
1050mA 42W 2 - 40V
862014 white 500mA 60,3W 2 - 90V 124 x 82 x 23 mm
600mA 60,3W 2 - 90V
700mA 60,3W 2 - 86V
900mA 60,3W 2 - 67V
1050mA 60,3W 2 - 57V
1400mA 60,3W 2 - 42V
220-240 CC max 60 M M
accessories
930412 SYNC cable for synchronization of max. 10 power supplies
with push function, length 300 cm
738 POWER SUPPLY | DC | indoor | constant power | dimmable via DALI or PUSH
