Page 741 - Deko-Light Light Impressions 2019-20
P. 741
TCI POWER SUPPLY JOLLY MD PUSH | DIMMABLE
dimmable via leading edge or touch dimmer-function [Push]
strom- [CC] or constant voltage [CV]
via DIP-switch adjustable
master/slave operation of several power supplies
via sync cable [accessories]
561201 white Jolly MD Push 165 x 48 x 35 mm
constant power 350mA 17W 2 - 43V
500mA 24W 2 - 43V
700mA 32W 2 - 36V
constant voltage 12V 10W
24V 20W
28V 22W
220-240 max 32 M M
CV CC
accessories
561202 SYNC cable for synchronization of max. 10 power supplies
with push function, length 150 cm
740 MULTI-POWER SUPPLY | DC | indoor | strom- or constant voltage
