Page 902 - Deko-light Catalogue 2022
P. 902
DEKO-LIGHT POWER SUPPLIES | DESIGN FLAT
plastic housing
suitable for indoor use design example
flicker free
short-circuit proof and overload protection
overheat control
872629 12V 6W 0-500mA 7A/300µs 98 x 46 x 11 mm 16,95 €
872632 12V 12W 0-1000mA 8A/300µs 128 x 50 x 13 mm 19,95 €
872635 12V 20W 0-1670mA 12A/300µs 128 x 50 x 14 mm 22,95 €
862121 12V 50W 0-4160mA 15A/300µs 185 x 62 x 22 mm 54,95 €
872630 24V 6W 0-250mA 7A/300µs 98 x 46 x 11 mm 16,95 €
872633 24V 12W 0-500mA 8A/300µs 128 x 50 x 13 mm 19,95 €
872636 24V 20W 0-830mA 12A/300µs 128 x 50 x 14 mm 22,95 €
862122 24V 50W 0-2100mA 15A/300µs 185 x 62 x 22 mm 54,95 €
220-240 CV max 50 IP20 M M
DEKO-LIGHT POWER SUPPLIES | DESIGN LONG-FLAT design example
plastic housing
suitable for indoor use
ideal for concealed mounting in ceiling coving
flicker free
short-circuit proof and overload protection
overheat control
862123 12V 45W 0-3750mA 30A/300µs 251 x 30 x 16 mm 49,95 €
862093 12V 60W 0-5000mA 30A/300µs 305 x 30 x 17 mm 59,95 €
862125 12V 100W 0-8340mA 50A/300µs 312 x 30 x 18 mm 96,95 €
862172 12V 150W 0-12500mA 60A/300µs 335 x 30 x 22 mm 134,95 €
862124 24V 45W 0-1870mA 30A/300µs 251 x 30 x 16 mm 49,95 €
862094 24V 60W 0-2500mA 30A/300µs 305 x 30 x 17 mm 59,95 €
862126 24V 100W 0-4170mA 50A/300µs 312 x 30 x 18 mm 96,95 €
862173 24V 150W 0-6250mA 60A/300µs 335 x 30 x 22 mm 134,95 €
220-240 CV max 150 IP20 M M
900 POWER SUPPLIES | DC | CV | not dimmable
