P. 904
design example
MEANWELL POWER SUPPLIES NPF-SERIES
plastic housing
suitable for indoor and outdoor use
flicker free
short-circuit proof and overload protection
overheat control
872097 12V 40W 0-3340mA 50A/270µs 150 x 53 x 35 mm 69,95 € new
872098 12V 60W 0-5000mA 50A/270µs 150 x 53 x 35 mm 74,95 € new
872099 12V 90W 0-7500mA 60A/550µs 171 x 63 x 38 mm 94,95 € new
872100 12V 120W 0-10000mA 60A/520µs 191 x 63 x 38 mm 119,95 € new
872101 24V 40W 0-1670mA 50A/270µs 150 x 53 x 35 mm 69,95 € new
872102 24V 60W 0-2500mA 50A/270µs 150 x 53 x 35 mm 74,95 € new
872103 24V 90W 0-3750mA 60A/550µs 171 x 63 x 38 mm 94,95 € new
872104 24V 120W 0-5000mA 60A/520µs 191 x 63 x 38 mm 119,95 € new
872105 48V 40W 0-840mA 50A/270µs 150 x 53 x 35 mm 69,95 € new
872106 48V 60W 0-1250mA 50A/270µs 150 x 53 x 35 mm 74,95 € new
872107 48V 90W 0-1880mA 60A/550µs 171 x 63 x 38 mm 94,95 € new
872108 48V 120W 0-2500mA 60A/520µs 191 x 63 x 38 mm 119,95 € new
90-305 CV max 120 IP67 M M
MEANWELL POWER SUPPLIES ELG/HLG-SERIES
aluminium housing
suitable for indoor and outdoor use
flicker free
short-circuit proof and overload protection
overheat control design example
output voltage/current adjustable/dimmable via int. potentiometers
872116 ELG 48V 75W 0-1600mA 50A/350µs 180 x 63 x 36 mm 84,95 € new
872119 ELG 48V 150W 0-3130mA 65A/550µs 219 x 63 x 36 mm 149,95 € new
872122 ELG 48V 240W 0-5000mA 60A/510µs 244 x 71 x 38 mm 179,95 € new
872125 HLG 48V 600W 0-12500mA 70A/1000µs 280 x 144 x 49 mm 429,95 € new
100-305 CV max 600 IP67 M M
902 POWER SUPPLIES | DC | CV | not dimmable
