Page 903 - Deko-light Catalogue 2022
P. 903
DEKO-LIGHT POWER SUPPLIES | DESIGN BASIC
plastic housing
suitable for indoor use design example
flicker free
short-circuit proof and overload protection
overheat control
862162 12V 40W 0-3000 mA 15A/300µs 166 x 52 x 24 mm 48,95 €
862127 12V 75W 0-6300 mA 15A/300µs 184 x 61 x 32 mm 74,95 €
862165 12V 100W 0-8300 mA 50A/300µs 184 x 61 x 32 mm 94,95 € new
862167 12V 150W 0-12500 mA 60A/300µs 210 x 67 x 34 mm 129,95 €
862163 24V 40W 0-1700 mA 15A/300µs 166 x 52 x 24 mm 48,95 €
862164 24V 75W 0-3100 mA 15A/300µs 184 x 61 x 32 mm 74,95 €
862166 24V 100W 0-4200 mA 50A/300µs 184 x 61 x 32 mm 94,95 €
862168 24V 150W 0-6250 mA 60A/300µs 210 x 67 x 34 mm 129,95 €
220-240 CV max 150 IP20 M M
DEKO-LIGHT POWER SUPPLIES | DESIGN IP
aluminium housing
suitable for indoor and outdoor use
flicker free
short-circuit proof and overload protection
overheat control design example
872082 12V 40W 0-3340 mA 30A/300µs 182 x 58 x 30,5 mm 69,95 €
872084 12V 75W 0-6250 mA 35A/300µs 186 x 64 x 39 mm 89,95 €
872093 12V 100W 0-8340 mA 50A/300µs 186 x 64 x 39 mm 109,95 €
872086 12V 150W 0-12500 mA 60A/300µs 191 x 70 x 40 mm 149,95 €
872088 12V 200W 0-16600 mA 75A/300µs 249 x 72 x 41 mm 165,95 €
872083 24V 40W 0-1670 mA 30A/300µs 182 x 58 x 30,5 mm 69,95 €
872085 24V 75W 0-3125 mA 35A/300µs 199 x 67 x 35 mm 89,95 €
872094 24V 100W 0-4170 mA 50A/300µs 186 x 64 x 39 mm 109,95 €
872087 24V 150W 0-6250 mA 60A/300µs 191 x 70 x 40 mm 149,95 €
872089 24V 240W 0-10000 mA 75A/300µs 249 x 72 x 41 mm 179,95 €
872091 24V 320W 0-13340 mA 85A/300µs 252 x 90 x 44 mm 209,95 €
110-240 CV max 320 IP67 M M
POWER SUPPLIES | DC | CV | not dimmable 901
