Page 923 - Deko-light Catalogue 2022
P. 923
DEKO-LIGHT POWER SUPPLY | BASIC
MULTI-CURRENT
plastic housing
suitable for indoor use
flicker free
short-circuit proof and overload protection
current range adjustable
dimmable with compatible [C-compatible]
trailing or leading edge phase dimmers
862141 350mA 3,20 - 14,00W 9-40V 15A/90µs 150 x 43 x 28 mm 41,95 €
400mA 3,60 - 16,00W 9-40V
450mA 4,00 - 18,00W 9-40V
500mA 4,50 - 20,00W 9-40V
550mA 5,00 - 19,80W 9-36V
600mA 5,40 - 19,80W 9-33V
650mA 5,90 - 19,50W 9-30V
700mA 6,30 - 19,60W 9-28V
220-240 CC max 20 IP20 M M
BASIC INFORMATION
ON THE USE OF DALI BALLASTS
DALI SINGLE DIMMER DALI BUS READY
DALI single dimmers cannot be integrated into existing These components can be integrated and controlled in
DALI networks. The control takes place via so-called single existing DALI BUS systems that comply with the IEC 62386
dimmers, which generate their own control signal. protocol.
DEKO-LIGHT POWER SUPPLY | BASIC
DALI CC DRIVER
plastic housing
suitable for indoor use
flicker free
short-circuit proof and overload protection
dimmable via DALI single dimmer
862057 350mA 0,70 - 20,00W 2-58V 30A/300µs 122 x 52 x 30 mm 44,95 €
220-240 CC 20 IP20 M M
POWER SUPPLIES | DC | CC | dimmable via leading or trailing edge / DALI single dimmer 921
