Page 919 - Deko-light Catalogue 2022
P. 919
design example
DEKO-LIGHT POWER SUPPLIES | DESIGN BASIC
plastic housing
suitable for indoor use
flicker free
short-circuit proof and overload protection
180512 350mA 0,70-18,00W 2-52V 10A/300µs 115 x 45 x 21 mm 23,95 €
180513 500mA 1,00-18,00W 2-38V 10A/300µs 115 x 45 x 21 mm 23,95 €
872665 500mA 10,00-30,00W 20-60V 5A/300µs 128 x 50 x 13 mm 25,95 €
862134 500mA 13,50-40,00W 27-80V 5A/300µs 154 x 50 x 14 mm 29,95 €
180514 700mA 1,40-18,00W 2-26V 10A/300µs 115 x 45 x 21 mm 23,95 €
862198 700mA 9,10-30,00W 13-43V 8A/300µs 142 x 50 x 24 mm 25,95 € new
862135 700mA 14,00-40,00W 20-57V 5A/300µs 142 x 50 x 24 mm 29,95 €
862157 900mA 19,80-40,00 W 22-44V 20A/300µs 127 x 43 x 28 mm 29,95 €
862133 1050mA 9,50-30,00W 9-28V 5A/300µs 142 x 50 x 24 mm 25,95 €
862201 1050mA 12,60-40,00W 12-38V 20A/300µs 142 x 50 x 24 mm 29,95 € new
220-240 CC max 40 IP20 M M
MEAN WELL POWER SUPPLY APC-SERIE
suitable for indoor use
872641 700mA 10,50-35,00W 15 - 50V 45A/490µs 84 x 57 x 29,5 mm 37,95 €
220-240 CC 35 IP30
POWER SUPPLIES | DC | CC | not dimmable 917
