Page 918 - Deko-light Catalogue 2022
P. 918
design example
DEKO-LIGHT POWER SUPPLIES | DESIGN FLAT
plastic housing
suitable for indoor use
flicker free
short-circuit proof and overload protection
872628 350mA 0,70-6,00W 2-18V 10A/300µs 98 x 46 x 11 mm 17,95 €
872631 350mA 0,70-12,00W 2-35V 12A/300µs 128 x 50 x 13 mm 21,95 €
872634 350mA 0,70-20,00W 2-57V 15A/300µs 154 x 50 x 14 mm 24,95 €
862130 500mA 1,00-6,00W 2-12V 10A/300µs 98 x 46 x 11 mm 17,95 €
862131 500mA 1,00-12,00W 2-24V 12A/300µs 128 x 50 x 13 mm 21,95 €
862132 500mA 1,00-20,00W 2-40V 15A/300µs 154 x 50 x 14 mm 24,95 €
862048 700mA 1,40-6,00W 2-9V 10A/300µs 98 x 46 x 11 mm 17,95 €
862049 700mA 1,40-12,00W 2-19V 12A/300µs 128 x 50 x 14 mm 21,95 €
862050 700mA 1,40-20,00W 2-31V 15A/300µs 128 x 50 x 14 mm 24,95 €
220-240 CC max 20 IP20 M M
HEP POWER SUPPLIES LIC/LIVC-SERIE
suitable for indoor use
872818 350mA 6,00-9,00W 17,1 - 25,7V 66A/0,9µs 58,1 x 39 x 20 mm 21,95 €
872826 500mA 6,00-9,00W 12 - 18V 68A/1,0µs 58,1 x 39 x 20 mm 21,95 €
110-240 CC max 9 IP20
916 POWER SUPPLIES | DC | CC | not dimmable
