6P4S Header 9P4S Header
With the Set 6P4S Header, the plug and socket unit are As the name suggests, the 9P4S set has nine primary
supplied twice. channels.

The complete From the front
scope of delivery with view of the
with installation mounting
template, fixing frames.
screws and
screwdriver.
The connection
sides.

From the left: Socket unit, plug
unit, rear of plug unit, rear of so-
cket unit, including template, fi-
xing screws and screwdriver.
9P4S Cable
The set 9P4S Cable broken down: nine primary, four
secondary channels and three meters of cable.

9P4S with three meter
cable. Clearly visible
are the three servo 9P4S Direct
cables, the retractable
landing gear cable and The complete scope
the two black cables for of delivery.
additional functions.

On the left the socket
part, on the right the
plug part with the fixing
clamps.

Left the socket part,
right the plug part.

Summary
With uniCONNECT, an innovative and safe connector system
has been created that covers all aspects of model aircraft con-
struction. If you are unsure about soldering, you should always
use the cable systems. Suitable plugs or sockets can be sol-
dered or crimped onto the cut cable ends. If you're standing on The advantage of the uniCONNECT
your head with a soldering iron, the Direct system will be the system is the integrated redundancy
right one for you. The "life insurance" mentioned at the begin-
ning is guaranteed in any case with uniCONNECT thanks to re- for important control functions. For this
dundancy. Further connector systems, also for simpler con- reason, a distinction is made between
nections, as well as more information and prices are available primary, double pins and secondary,
on the net at www.unilight.at
JP single pins.
