                   13. Transformer , Diodes, Zener Diodes

               OUTCOMES:
               On completion of the course students will be able to
                      •  design rectifier, voltage regulator and Zener diode circuits for the given specifications
                      •  design the different types of clipper and clamper circuits using Diode
                      •  design the Fixed, Collector to base, emitter bias and voltage divider bias circuits using
                          BJT
                      •  design feedback amplifier, power amplifier and sine wave oscillator circuits using BJT
                      •  design multivibrator circuits using BJT for generating time delay.



                BM17313                           PCB DESIGN LABORATORY                           L  T  P  C
                                                                                                  0  0  2  1

               OBJECTIVES
                   •  To familiarize the electronic components and basic electronic instruments
                   •  To make students familiar with PCB design and various processes involved
                   •  To provide in-depth core knowledge in the fabrication of Printed
                   •  To provide the knowledge in assembling and testing of the PCB based electronic circuits
                   •  To provide knowledge on designing of real time PCB boards.

               List of Experiments
                   1.  Study of Electronic Components
                          a.  Resistors, capacitors, inductors.
                          b.  Transformers, Diodes, transistors
                          c.  Integrated Circuits, Display, Switches
                   2.  Study of Instruments and Equipments (DMM, Power supply, CRO, FG)
                   3.  Generation of CAM Files for single side PCB (Measuring voltage Drop)
                   4.  Generation of CAM Files for single side PCB (Full wave Rectifier)
                   5.  PCB Assembly and Testing (Measuring voltage Drop)
                   6.  PCB Assembly and Testing (Full wave Rectifier)
                   7.  Study of single side PCB Fabrication process by photo resist Method.

                                                                                        TOTAL: 30 PERIODS
               LAB REQUIREMENT FOR A BATCH OF 30 STUDENTS
                   1.  Computers with ORCAD software – 30 Nos.
                   2.  Multimeter – 15 Nos.

               OUTCOMES:
               On completion of the course students will be able to
                   •  Design lay out for a circuit with suitable dimensions of the devices
                   •  Validate the design before implementing
