Page 6 - TAV CATELOGUE RGB

IND US TRIA L COM M ERCIAL LIG HTIN G

³

V APOUR PROOF

FIT TIN G

ELECTRONIC BALLAST
NARROW BODY

CODE LENGTH WIDTH HEIGHT A1 A2 CLIPS MAX WATT IP LAMP
SA0004B 1260 120 86 900 1000 8 2x36W IP65 T8 FLUORESCENT TUBE
SA0001B 1560 120 86 1000 1200 10 2x58W IP65 T8 FLUORESCENT TUBE

V APOUR PROOF

FIT TIN G

ELECTRONIC BALLAST
WIDE BODY

CODE LENGTH WIDTH HEIGHT A1 A2 CLIPS MAX WATT IP LAMP
SA0004 1268 163 105 900 1000 8 2x36W IP65 T8 FLUORESCENT TUBE
SA0001 1568 163 105 900 1200 10 2x58W IP65 T8 FLUORESCENT TUBE

V APOUR PROOF

FIT TIN G

LED WIRED
4FT & 5FT

CODE LENGTH WIDTH HEIGHT A1 CLIPS IP LAMP
SA0004A 1260 135 95 960 10 IP65 T8 LED TUBE
SA0001A 1560 135 95 1240 12 IP65 T8 LED TUBE
