Page 47 - a compendium of pipe repair clamps - Pipe couplings and tapping equiptment 2016_Neat

2-570/590-16 570 - 590 400 M16 x 10
2-570/590-24 570 - 590 600 M16 x 16
2-580/600-16 580 - 600 400 M16 x 10
2-580/600-24 580 - 600 600 M16 x 16
2-600/620-16 600 - 620 400 M16 x 10
2-600/620-24 600 - 620 600 M16 x 16
2-620/640-16 620 - 640 400 M16 x 10
2-620/640-24 620 - 640 600 M16 x 16

REPAIR CLAMPS THREE PART OTHER
SIZES AND LENGTHS AVAILABLE
PART NO RANGE Clamp Length (mm) Bolt size x No. of bolts
3-490/520-16 490 - 520 400 M16 x 15
3-490/520-24 490 - 520 600 M16 x 24
3-520/550-16 520 - 550 400 M16 x 15
3-520/550-24 520 - 550 600 M16 x 24
3-550/580-16 550 - 580 400 M16 x 15
3-550/580-24 550 - 580 600 M16 x 24
3-560/590-16 560 - 590 400 M16 x 15
3-560/590-24 560 - 590 600 M16 x 24
3-590/620-16 590 - 620 400 M16 x 15
3-590/620-24 590 - 620 600 M16 x 24
3-610/640-16 610 - 640 400 M16 x 15
3-610/640-24 610 - 640 600 M16 x 24
3-650/680-16 650 - 680 400 M16 x 15
3-650/680-24 650 - 680 600 M16 x 24
3-690/720-16 690 - 720 400 M16 x 15
3-690/720-24 690 - 720 600 M16 x 24
3-720/750-16 720 - 750 400 M16 x 15
3-720/750-24 720 - 750 600 M16 x 24
3-750/780-16 750 - 780 400 M16 x 15
3-750/780-24 750 - 780 600 M16 x 24
3-780/810-16 780 - 810 400 M16 x 15
3-780/810-24 780 - 810 600 M16 x 24
