Page 44 - a compendium of pipe repair clamps - Pipe couplings and tapping equiptment 2016_Neat

Part No. Range (mm) Clamp Length (mm) Bolt size x No. of bolts
1-0520-08 130 - 140 200 M16 x 2
1-0520-12 130 - 140 300 M16 x 3
1-0520-16 130 - 140 400 M16 x 4
1-0520-24 130 - 140 600 M16 x 6
1-135/145-08 135 - 145 200 M16 x 2
1-135/145-12 135 - 145 300 M16 x 3
1-135/145-16 135 - 145 400 M16 x 4
1-135/145-24 135 - 145 600 M16 x 6
1-0590-08 145 - 155 200 M16 x 2
1-0590-12 145 - 155 300 M16 x 3
1-0590-16 145 - 155 400 M16 x 4
1-0590-24 145 - 155 600 M16 x 6
1-0600-08 151 - 161 200 M16 x 2
1-0600-12 151 - 161 300 M16 x 3
1-0600-16 151 - 161 400 M16 x 4
1-0600-24 151 - 161 600 M16 x 6
1-160/170-08 160 - 170 200 M16 x 2
1-160/170-12 160 - 170 300 M16 x 3
1-160/170-16 160 - 170 400 M16 x 4
1-160/170-24 160 - 170 600 M16 x 6
1-0663-08 167 - 178 200 M16 x 2
1-0663-12 167 - 178 300 M16 x 3
1-0663-16 167 - 178 400 M16 x 4
1-0663-24 167 - 178 600 M16 x 6
1-0690-08 174 - 183 200 M16 x 2
1-0690-12 174 - 183 300 M16 x 3
1-0690-16 174 - 183 400 M16 x 4
1-0690-24 174 - 183 600 M16 x 6
1-0745-08 189 - 199 200 M16 x 2
1-0745-12 189 - 199 300 M16 x 3
1-0745-16 189 - 199 400 M16 x 4
1-0745-24 189 - 199 600 M16 x 6
1-0790-08 196 - 205 200 M16 x 2
1-0790-12 196 - 205 300 M16 x 3
1-0790-16 196 - 205 400 M16 x 4
1-0790-24 196 - 205 600 M16 x 6
1-0800-08 202 - 212 200 M16 x 2
1-0800-12 202 - 212 300 M16 x 3
1-0800-16 202 - 212 400 M16 x 4
1-0800-24 202 - 212 600 M16 x 6
1-0863-08 218 - 228 200 M16 x 2
1-0863-12 218 - 228 300 M16 x 3
1-0863-16 218 - 228 400 M16 x 4
1-0863-24 218 - 228 600 M16 x 6
1-0900-08 229 - 238 200 M16 x 2
