PREMIUM MODULAR WORKBENCH
Superior Quality For Years Of Dependability!
Premium quality modular workbenches allow you to choose the bench that best fits your needs.
Strong, all welded steel construction is tough enough for any application. Choose from seven pedestal
1
3
configurations plus eight top styles. Inside drawer dimensions are 13”W x 17 /4”D x 5 /2”H (12”H for the
lower drawer on the three drawer pedestal). Cabinet pedestal features adjustable shelf and cylinder lock.
Pedestal dimensions are 15 /4”W x 20”D x 32”H.
3
Style Description OPTIONAL POWER RISER APRON POWER
A. 1-4 DRAWER PEDESTAL Includes grounded eight CENTER
outlet wiring kit, circuit
1- CABINET PEDESTAL breaker, pilot light, 8’L
B. 2-3 DRAWER PEDESTAL grounded cord and plug. 15 36”W panel includes
C. 1-3 DRAWER PEDESTAL amps, 115V. 18”H x 15”D. circuit breaker
1- CABINET PEDESTAL with 8 grounded
D. 2- CABINET PEDESTAL Model W” outlets, pilot light,
E. 2-4 DRAWER PEDESTAL SC607701 60 8’L grounded cord
F. 1-4 DRAWER PEDESTAL SC607702 72 and plug. For use
G. 1-4 DRAWER PEDESTAL SC607617 with 72”W benches,
1-3 DRAWER PEDESTAL except style F.
Drawers glide on nylon rollers and feature full- Model SC249512
length aluminum pulls and individual cylinder locks.
A B C D E F G
W” x D” Model Model Model Model Model Model Model
MAPLE-1 3 /4” Thick Top
60 x 24 SC253776 SC253780 SC253784 SC253788 SC253792 --- SC253800
60 x 30 SC607616 SC607628 SC607640 SC607652 SC607664 SC607676 SC607688
72 x 24 SC253777 SC253781 SC253785 SC253789 SC253793 --- SC253801
72 x 30 SC607617 SC607629 SC607641 SC607653 SC607665 SC607677 SC607689
PLASTIC-1 5 /8” Thick Top
60 x 24 SC253778 SC253782 SC253786 SC253790 SC253794 --- SC253802
60 x 30 SC607618 SC607630 SC607642 SC607654 SC607666 SC607678 SC607690
72 x 24 SC253779 SC253783 SC253787 SC253791 SC253795 --- SC253803
72 x 30 SC607619 SC607631 SC607643 SC607655 SC607667 SC607679 SC607691
ESD -1 1 /4” Thick Top
60 x 30 SC607620 SC607632 SC607644 SC607656 SC607668 SC607680 SC607692
72 x 30 SC607621 SC607633 SC607645 SC607657 SC607669 SC607681 SC607693
SHOP TOP-1 1 /2” Thick Top
60 x 30 SC300733 SC300735 SC300737 SC300739 SC300741 SC300743 SC300745
72 x 30 SC300734 SC300736 SC300738 SC300740 SC300742 SC300744 SC300746
MAPLE SAFETY EDGE-1 3 /4” Thick Top BENCH
60 x 30 SC607622 SC607634 SC607646 SC607658 SC607670 SC607682 SC607694
72 x 30 SC607623 SC607635 SC607647 SC607659 SC607671 SC607683 SC607695
PLASTIC SAFETY EDGE-1 5 /8” Thick Top
60 x 30 SC607624 SC607636 SC607648 SC607660 SC607672 SC607684 SC607696
72 x 30 SC607625 SC607637 SC607649 SC607661 SC607673 SC607685 SC607697
ESD SAFETY EDGE-1 1 /4” Thick Top
60 x 30 SC607626 SC607638 SC607650 SC607662 SC607674 SC607686 SC607698
72 x 30 SC607627 SC607639 SC607651 SC607663 SC607675 SC607687 SC607699
SHOP TOP-1 3 /4” Thick Top
60 x 30 SC300747 SC300749 SC300751 SC300753 SC300755 SC300757 SC300759
72 x 30 SC300748 SC300750 SC300752 SC300754 SC300756 SC300758 SC300760
PROLINE HEAVY DUTY
BENCHES Perfect For Lab
Sturdy four leg design provides stability and strength. and Shop Use
Table top is reinforced using a metal perimeter around
the frame. Bench is made using heavy 2” x 2” 16 gauge
steel tube legs with high quality paint finish. Legs include W” x D” x H” Top Construction Color Model
PVC boots to protect station during clean ups. 1,000 lb. 60 x 30 x 32 Chem Guard Square Edge White SC249756
capacity. Bench top is available in Stainless Steel, Epoxy 60 x 30 x 30 Stainless Steel Square edge White SC249758
Resin or Black Chem-Guard (chemical resistant laminate). 60 x 30 x 34 Phenolic Resin Square Edge White SC249757
ANTI-STATIC WORKSURFACE MATS
• Excellent for use in assembly operations where matting may
come in contact with hot soldering iron tips or solder splashes
• Volume electrical properties protect static sensitive products
• Static dissipative top layer with a conductive bottom of synthetic
rubber
• Slight stipple finish, RTT: 10E8 ohms, Thickness: 0.078”, Blue
color Model Description
• Includes one installed 10mm snap socket SC242251 2’ x 3’ Mat
• Optional Hardware Kit includes: wrist strap, common point SC242252 2’ x 4’ Mat SC242253
ground and mat hardware kit to ground workers for safety SC242253 Hardware Kit
155
