Page 80 - US ACCESSORIES GUIDE (2019)

OUTBOARD

HEX NUT SEAL KIT OUTBOARD

11-826711 17 26- 89238A 2
Hex Nylock Nut, brass Fits Mercury / Mariner 135/150 V‑6 outboards (USA 0A904646 and Newer) and
Fits current Mercury/Mariner 40 hp. thru V‑6 outboards (2‑cycle and FourStroke), 175/200 V‑6 outboards (USA 6618751 and Newer).
and also fits Force 40‑120 hp. outboards (USA 0E009500 and Newer). Also
shipped standard with the 135‑275 hp. Verado outboard. GEARCASE ASSEMBLY COMPLETE
OUTBOARD MOUNTING HARDWARE CHART

Used for permanent mounting of an engine to the boat transom.

Transom Mounting Bolt Kit Chart
Outboard Mounting Hardware Chart

Thread Length Bolt Length (Inches) Individual / Kit Part Number
(Inches)
1647- 9148T81
1.25 2.5 Kit 10- 67755A22 Black, 2:1 ratio. 20" long shaft. 14 pinion teeth.
Individual 10- 67755005 Standard Rotation (RH).
Fits Mercury 135‑200 (2.5L) V‑6 outboards
1.25 3.5 Kit 10- 67755A26
Individual 10-8M0131814 HIGH ALTITUDE GEAR SETS & GEARCASES (4
2.25 4 Individual 10-814259
2.25 4.5 Kit 10- 67755A13 CYLINDER)
Individual 10- 67755 1 Due to a loss of horsepower at high altitudes, a lower gear reduction
3.25 5.5 Kit 10- 67755A14 (higher numerical ratio) will enhance performance.
Individual 10-8M0038370
2.75 6.5 Kit 10- 67755A15 PINION/FORWARD GEAR ASS'Y. (WITH FORWARD
BEARING)
Individual 10- 67755 2
2.75 7.5 Kit 10- 67755A17
Individual 10-8M0028080
2.75 8 Kit 10- 67755A18
Individual 10-8M0032860

HIGH ALTITUDE GEAR SETS & GEARCASES (V-6)

Due to a loss of horsepower at high altitudes, a lower gear reduction
(higher numerical ratio) will enhance performance.
43-803500T 1
HIGH ALTITUDE GEAR SET Converts to a 2.3 ratio. Reverse gear and a seal or seal & bearing kit also required.
Fits Mercury/Mariner 100/115/125 hp. 2‑cycle outboard (USA 0B209468 and
Newer, BEL 9523034) with 3 jaw reverse clutch.

43- 44102A 2
175/200 Gear Set, converts ratcheting style 1.87:1 ratio to a 2:1 ratio.
Fits Mercury / Mariner 175/200 hp. V‑6 outboards with ratcheting clutch.

2019 US Accessories Guide 67
