Page 142 - Quicksilver Marine Parts Guide (2020) - 8M0163275

QUICKSILVER PROPELLER TYPE

QUICKSILVER Q3 90 CT - 400 HP QUICKSILVER Q4 40 CT - 125 HP

The Q3 is a revolutionary propeller that improves both acceleration and The aggressive 4‑blade Q4 generates exceptional lift resulting in a
top speed on center consoles, high horsepower pontoons, and propeller that provides outstanding holeshot, unmatched midrange
sterndrive powered runabouts. The design consists of high rake angles performance and superior handling, all while running at best‑in‑class
and thin blades resulting in the Q3 being the highest performing 3‑blade top speeds. The new Q4 is the ideal match on a wide range of boat QUICKSILVER PROPELLER TYPE
propeller in the Quicksilver line‑up. types (Bass, Multi‑Species, Fish and Ski, Center Console, Bay,
Pontoon).
Equipped with PVS ‑ Performance Vent System
Equipped with PVS ‑ Performance Vent System
Use Flo‑Torq SSR HD hub kit 8M0101603 when installing a Q3 Flo‑Torq SSR (8M0150152) hub system not included
propeller on a Mercury FourStroke V8 and 350 ‑ 400 HP Verado
Outboards. Q4 PROPELLER
Flo‑Torq SSR (8M0150152) hub system not included
QUICKSILVER Q3 PROPELLER

48-8M0055559
14 X 13 SS RH 4BL
48-8M0055560
13.5 x 15 SS RH 4 BL
48-8M0103516
16 x 11 RH SS 3 BL 48-8M0055561
48-8M0103517 13.0 x 17 SS RH 4BL
15.6 x 13P RH SS 3 BL 48-8M0055562
48-8M0103518 12.7 x 19 SS RH 4BL
15.3 x 14P RH SS 3 BL 48-8M0055563
48-8M0103519 12.7 x 21 SS RH 4BL
15.0 x 15P RH SS 3 BL
48-8M0103520
14.7 x 16P RH SS 3 BL
48-8M0103521
14.5 x 17P RH SS 3 BL
48-8M0103522
14.2 x 18P RH SS 3 BL
48-8M0103523
14.0 x 19P RH SS 3 BL
48-8M0103525
13.6 x 21P RH SS 3 BL

Marine Engine Parts 137
