P. 147

PROPELLER HARDWARE



            Application  Flo-Torq II Hub Kit  Forward Trust  Drive Sleeve  Bushing  Aft Adaptor  Aft Spacer/ Washer  Nut  Cotter Pin
                                  Washer
            Stroke (1998-2008),
            75-140 HP 2-Stroke
            Suzuki 70-90 HP  835283Q03  12-8M0042329  835290Q 1  N/A  826074Q 1  12-887972  859939   18- 47959
            (2009 and newer)
            Suzuki 90-115 HP 4-  835283Q 1  12-888939  835290Q 1  N/A  826074Q 1  12-887972  859939  18- 47959
            Stroke (2001-2008)
            Suzuki 140 HP 4-  835283Q 2  12-835467008  835290Q 1  N/A  826074Q 1  12-887972  859939  18- 47959
            Stroke, 100-115 HP
            4-Stroke (2009 and
            newer)
            Suzuki 150-300 HP  835281Q 1  12-853359  835290Q 1  N/A  826074Q 1  12- 31211Q03  859939  18- 47959
            Tohatsu/Nissan  835284Q 1  12-853948T  835290Q 1  N/A  826074Q 1  12- 16140  11- 16147   18-815026
            60-140 HP
            (1) Use hub kit only with Quicksilver small lybrinth seal propellers: QA2202X thru QA2208X, QA 3828X thru QA3832X and QS5136X thru QS5144X.

            FLO-TORQ REFLEX HUB KITS                            FLO-TORQ II & SSR HUB KITS

      PROPELLER HARDWARE
            FLO-TORQ REFLEX HUB KIT QUICKSILVER
                                                                Quicksilver Propellers can improve improve performance of any Boat.
                                                                Use the following Flo‑Torq II chart for proper hardware selection.










                 835257Q12
            Kit includes: Forward thrust washer, Reflex drive sleeve (8M0047148), Aft Washer
            and Prop Nut (8M0045381).
            Mercury/Mariner 40‑60 HP FourStroke (not CT/BigFoot), 30 HP FourStroke
            1994‑2005, 30‑60 HP 2‑Stroke 1977 and newer, 25 HP CT/BigFoot, 55 HP
            SeaPro/Marathon, Yamaha 40‑60 HP (Excluding 50T and 60T), Honda 40‑50 HP
            with separately purchased 8M0046466 Thrust Washer, Suzuki 35‑60 HP with
            separately purchased 8M0088039 Thrust Washer, Tohatsu 35‑50 hp with
            separately purchased 8M0053074 Thrust Washer
            Quicksilver Branded, Hanging Box Point of Sale Packaged.
            DRIVE SLEEVE












                 8M0047148
            Plastic drive sleeve Flo‑Torq Reflex Composite Drive Sleeve















            142
