Page 140 - Latin America Accessories Guide (2020) - 8M0163252

MERCRUISER

SERPENTINE BELT 57-865615Q02
2285 mm length
Fits 2001‑2004 MIE 8.1S engines (s/n 0M025000‑0W389999). Also fits 2001‑2005
MCM 496 Mag engines (s/n 0M025000‑0W309999) that the power steering pump
has been removed.
P/S HOSE COUPLER

57-865615Q08
2535 mm length
Fits 1999‑2002 MCM V‑6 & V‑8 (305, 350 & 377 cid) Bravo engines with high
mounted alternator that the power steering pump is being removed (s/n
0L619000‑0M343007).
57-865615Q09 22-860099001
1780 mm length Required kit when leaving the power steering pump on the second engine in dual
Fits 1999‑2001 MCM V‑6 & V‑8 (305 & 350 cid) Alpha engines with high mounted engine applications. Connects the power steering hoses together.
alternator (s/n 0L619000‑0M320024) Fits all MCM engines with power steering
57-865615Q07
2467 mm length
Fits 1998‑2001 MCM V‑8 (454 & 502 cid) Bravo engines with serpentine belt that
the power steering pump is being removed. MERCRUISER

SERPENTINE BELT KIT CHART

MCM Serpentine Belt Kits
For use on engines with power steering pump removed
Model Year Range Serial # Range Belt Kit Optional Brass Coupler
MCM V-6 (Gen +) Alpha 1996 - 1999 0F803000 - 0L619083 N.L.A. 22-860099001
MCM V-6 (Gen +) Alpha 1999 - 2002 0L619084 - 0M320024 57-865615Q09 22-860099001
MCM V-6 (Gen +) Alpha 2002 0M320025 - 0M343007 57-865615Q09(1) 22-860099001
MCM V-6 (Gen +) Alpha, RWC 2002 - 2003 0M343008 - 0M999999 889432A 1 22-860099001
MCM V-6 (Gen +) Alpha, FWC 2002 - 2003 0M343008 - 0M999999 889433A 1 22-860099001
MCM V-6 (Gen +) Bravo 1996 - 1999 0F803000 - 0L619083 807901A 3 22-860099001
MCM V-6 (Gen +) Bravo 1999 - 2002 0L619084 - 0M320024 57-865615Q08 22-860099001
MCM V-6 (Gen +) Bravo 2002 0M320025 - 0M343007 57-865615Q08(2) 22-860099001
MCM V-6 (Gen +) Bravo 2002 - 2003 0M343008 - 0M999999 889433A 1 22-860099001

MCM V-8 (305 & 350 cid) Alpha 1997 - 1999 0K001506 - 0L618999 N.L.A. 22-860099001
MCM V-8 (305 & 350 cid) Alpha 1999 - 2002 0L619000 - 0M320024 57-865615Q09 22-860099001
MCM V-8 (305 & 350 cid) Alpha 2002 0M320025 - 0M343007 57-865615Q09(1) 22-860099001
MCM V-8 (305 & 350 cid) Alpha, RWC 2002 - 2003 0M343008 - 0M999999 889432A 1 22-860099001
MCM V-8 (305 & 350 cid) Alpha, FWC 2002 - 2003 0M343008 - 0M999999 889433A 1 22-860099001
MCM V-8 (305 & 350 cid) Bravo 1998 - 1999 0K001506 - 0L618999 807901A 3 22-860099001
MCM V-8 (305, 350 & 377 cid) Bravo 1999 - 2002 0L619000 - 0M320024 57-865615Q08 22-860099001
MCM V-8 (305, 350 & 377 cid) Bravo 2002 0M320025 - 0M343007 57-865615Q08(2) 22-860099001
MCM V-8 (305, 350 & 377 cid) Bravo 2002 - 2003 0M343008 - 0M999999 889433A 1 22-860099001

MCM V-8 (454 cid) 1998 - 2001 0L010003 - 0M024999 57-865615Q07 22-860099001
MCM V-8 (496 cid) 2001 - 2003 0M025000 - 0W000004 57-865615Q02 22-860099001
MCM V-8 (502 cid) 1998 - 2001 0L017000 - 0M024999 57-865615Q07 22-860099001
(1) 889432A 1 Serpentine Belt Kit: Order this belt kit instead of the one listed if the engine has a 4-1/4 in.(108 mm) diameter grooved idler pulley.
(2) 889433A 1 Serpentine Belt Kit: Order this belt kit instead of the one listed if the engine has a 4-1/4 in.(108 mm) diameter grooved idler pulley.
