MERCRUISER

OIL DRAIN KIT OIL DRAIN KIT

32-865278A04 32-865281A02
Includes special tether so oil drain hose can be pulled out through the boat bilge Includes special tether so oil drain hose can be pulled out through the boat bilge
drain hole to drain engine oil. Boat needs to be removed from the water to take drain hole to drain engine oil. Boat needs to be removed from the water to take
advantage of this feature. advantage of this feature.
Fits 2009‑2016 and newer MCM V‑6 MPI engines (s/n 1A343329 thru 2A528897). Fits 1996 and up MCM V‑8 engines with metric M12 oil pan drain plug threads.
Also fits 4.5L V6 engines.

OIL DRAIN HOSE KIT CHART
MERCRUISER MCM Oil Drain Hose Kits Model Notes Year Range Serial # Range Oil Drain Hose Kit with Tether

Model

MCM 4 cyl. (153 & 181 cid) 1983 - 2016 6229718 - 2A506300 32-865277A02
MCM V-6 (229cid) 1983 - 1984 6330183 - 6919655 32-865277A02
MCM V-6 (262cid) 1985 - 1996 0A331455 - 0F802999 32-865277A02
MCM V-6 (262cid) Cast aluminum oil pan 1996 0F803000 - 0K000000 (1)
MCM V-6 (262cid) 1997 - 2000 0K000001 - 0M000000 32-865278A03
MCM V-6 (262cid) Jackshaft models 1999 - 2012 0L320000 and up N.L.A.
MCM V-6 (262cid) MPI engines 2009 - 2016 1A343329 - 2A528897 32-865278A04
MCM V-6 4.5L MPI engines 2014 - 2019 2A441953 and up 32-865281A02

MCM V-8 (305 & 350cid) 1/2-20 oil plug threads 1983 - 1995 6218462 - 0F600999 32-865277A02
MCM V-8 (305, 350 & 377cid) 12MM oil plug threads 1996 - 2015 0F601000 - 2A455872 32-865281A02
MCM V-8 (305, 350 & 377cid) MPI engines 2009 - 2015 1A342186 - 2A455878 32-865281A02
MCM V-8 6.2L Mercury MPI engines 2016 - 2019 2A456613 and up 32-865281A02

MCM V-8 (454cid) 1/2-20 oil plug threads 1982 - 1996 6083145 - 0F800699 32-865277A02
MCM V-8 (454cid) 12MM oil plug threads 1996 - 2001 0F800700 - 0M024999 32-865281A02

MCM V-8 (496cid) 12MM oil plug threads 2009 - 2012 1A349411 - 1A352731 32-865281A02

MCM V-8 (502cid) 1/2-20 oil plug threads 1990 - 1993 0C878221 - 0F802599 32-865277A02
MCM V-8 (502cid) 12MM oil plug threads 1996 - 2019 0F802600 - 0M024999 32-865281A02
(1) Kit not available
