Page 219 - Latin America Accessories Guide (2020) - 8M0163252

RACING

X-HAUST NOISE REDUCER CLOSE COUPLE TAILPIPE KIT - STAGE 1

Exhaust noise reduction system. Is compatible with both side‑by‑side
(close couple) or staggered (driveline) engine installations depending on
specific engine model. The Stage 1 system by itself limits idle noise
levels to 88dBA. The Stage 1 system combined with the Stage 2 muffler
kit will beat the stringent European Union (EU) Recreational Craft
Directive (RCD) noise emission standard. Also provides compliance for
most existing state or regional regulations that require a pass by test
here in the United States. For use on Race 520, 540, 565, 600 SCi, EU
662 SCi and 700 SCi sterndrive engines. 8M8023624
Port outlet. Requires 1 each 8M8023358 hardware kit for each tailpipe kit ordered.
X-HAUST STAGE 1 TAILPIPE KITS For use on 540, 565, 600 SCi, EU662 SCi and 700 SCi sterndrive engines.
CLOSE COUPLE TAILPIPE KIT - STAGE 1
CLOSE COUPLE TAILPIPE KIT - STAGE 1

8M8023625
Starboard outlet. Requires 1 each 8M8023358 hardware kit for each tailpipe kit
ordered.
For use on 540, 565, 600 SCi, EU662 SCi and 700 SCi sterndrive engines.
8M0094135 DRIVELINE TAILPIPE KIT - STAGE 1
520 Port outlet. Kit includes all mounting hardware.
For 520 close couple engines only. Both single and twin engine applications. Can
be used with standard steering and all Bravo XR drives. Or the Axius steering
system when installed with Bravo 3XR stern drives only.
CLOSE COUPLE TAILPIPE KIT - STAGE 1

8M8023626
Port outlet. Requires 1 each 8M8023359 hardware kit for each tailpipe kit ordered.
For use on 540, 565, 600 SCi, EU662 SCi and 700 SCi sterndrive engines.
DRIVELINE TAILPIPE KIT - STAGE 1

RACING 520 Starboard outlet. Kit includles all mounting hardware.
8M0094136

For 520 close couple engines only. Both single and twin engine applications. Can
be used with standard steering and all Bravo XR drives. Or the Axius steering
system when installed with Bravo 3XR stern drives only.
EXHAUST COUPLER ASSEMBLY
8M8023627
Starboard outlet. Requires 1 each 8M8023359 hardware kit for each tailpipe kit
ordered.
For use on 540, 565, 600 SCi, EU662 SCi and 700 SCi sterndrive engines.

8M0123001
Exhaust coupler 10.5"
To be used when taller exhaust than standard is used on the 520
